A338 Manual Steel Strapping Tool

Characteristics

Strapping qualities: Uniflex and Ultraflex max. 1100 N/mm2 / 160’000 psi
Strapping dimensions:
widths = 12.7 – 19.0 mm / 1/2″ – ¾”
thicknesses = 0.50 – 0.70 mm / .020 – .028”
Weight: 5.7 kg / 12.6 lbs Normal-version  (5.9 kg / 13.0 lbs. TW-version)
Average seal strength: approx. 80 %
Suspension (Optional): Suspension for vertical and horizontal applications; has to be ordered separately Handle for horizontal applications; has to be ordered separately

Advantages

The special tensioning gear-system allows a high strap tension of up to 5,500 N (1,240lbs)
The tool can handle regular duty and high tensile steel strapping.
The tool can handle steel strapping up to a thickness of 0.70 mm / .028”.
The adjustment of the cutting and sealing depth is simple.
The feed wheel and the die and cutter support are easy to change
