Rollbag R785 Automatic Bagger

All-Electric Tabletop Automatic Bagging System

The Rollbag™ R785 is a unique, all-electric tabletop automatic poly bagger. This compact automatic bagger uses the same electronics as our larger floor standing baggers, delivering a dependable, industrial quality, multi-shift packaging solution. Using an advanced control system, the R785 is able to operate at a rate of up to 40 bags/min, ensuring that machine speed is not the limiting factor in your packaging operation.

Operating Benefits

• Operate with a footswitch, by hand, or in auto cycle mode
• Adjustable height articulating load shelf to support the bag during packaging (13” max bag length)
• Seal flattener fingers minimize wrinkles in the seal area by stretching the bag prior to selling
• Print and apply a label directly on the next bag being fed out (optional)
• Compact design takes up minimal footprint in the packaging area
• 7” color touchscreen with user-friendly interface and clear prompts

Set-Up Benefits

• Utilizes Rollbag pre-opened bags-on-a-roll for quick bag size changes and easy set-up
• PLC with job storage, batch counters, packaging statistics, and login-in levels
• Ceramic heating element for fast start-up

Maintenance Benefits

• Off the shelf modular components for easy replacement
• Remote networking capability for improved troubleshooting
• Self-diagnostics ensure quick problem solving
• Quick service access to all electrical components
• Comprehensive 5 year warranty (optional)

Safety Benefits

• Zero force seal bar closing virtually eliminates the chance of injury
• Low power consumption design (500 Watts)
• CE compliant design for improved safety and troubleshooting

Options

• Air Expeller - This device presses against the bag prior to sealing, removing excess air. This option is ideal when there is no vent hole in the bag.

• Label Printer Applicator - An integrated 203dpi industrial label printer applicator. With this option you can automatically print and then apply a label onto the next bag to be fed out.

• FBA Seller Package – Fulfillment made easy with the label template and the equipment to add your label information for each bag to be labeled and sealed.

• Easy Touch Start Sensor – Start the sealing cycle with an optical sensor for improved ergonomics.

• NiceLabel Designer Pro Label Software - While our label printer applicator works with various types of label software, we recommend and support NiceLabel Designer Pro.

• Machine Stand - Adjustable height stand. Available with casters to move machine around.

Technical Specifications

Speed:                            Up to 40 bags/min (up to 30 bags/min with label printer applicator)

Bag Width:                       2" ‒ 12"

Bag Length:                     3” – 20”

Bag Gauge:                      1 – 4 mil (10” max roll diameter)

Seal Width:                      1/8”

Seal Bar Opening:            4”

Dimensions:                     26” W x 18” D x 24” H (24” D with label printer applicator)

Weight:                            105 lbs

Electrical                          120V, 5A

Warranty                          1 year limited warranty, extended up to 5 years when using Rollbag material
